18 gennaio 2022, 22:26:15

DWR-2101: Hotspot Mobile 5G Wi-Fi 6

Aperto da Pondera, 14 luglio 2020, 15:10:43


14 luglio 2020, 15:10:43 Ultima modifica: 13 marzo 2021, 11:12:31 di Pondera
Hotspot Mobile 5G Wi-Fi 6

DWR-2101 A1 (Qualcomm Snapdragon X55)
5260 mAh Li-ion battery

High-speed 5G and Wi-Fi 6
The latest in mobile and Wi-Fi technologies combine to give you the fastest mobile experience yet

Status at a Glance
The 2.4" color LCD touchscreen display is simple and intuitive, telling you the status of your device at a glance

Go Anywhere
The DWR-2101 is small enough to fit in your pocket, and its rechargeable battery means you're not tied to a wall outlet

• Uses a 5G or 4G/LTE nano SIM card to connect to the Internet
• Network speeds up to 1.6 Gbps¹
• Built-in AX1800 Wi-Fi 6²
• USB-C port for faster charging and future compatibility

• 2.4" color LCD touchscreen
• Portable, compact and light - designed to go wherever you go
• Intuitive touchscreen interface display for up-todate device status
• Versatile design lays flat for discreet positioning or stands upright for easy viewing

Battery Life
• Up to 10 hours of battery in one charge so you stay connected longer
• Rechargeable/removable 5260 mAh Li-Ion battery

Meet the DWR-2101, the world's first 5G and Wi-Fi 6 harnessing mobile hotspot. Bring revolutionary 5G speeds into your home and unleash the full power of Wi-Fi 6 for all your connected devices. The convenient size means you can share your connection anywhere; use it in a cafe to send e-mails while your friend reads the news, or at the airport so you and your co-workers can work while waiting for your plane. Never go anywhere without your Wi-Fi again.

Welcome Home, 5G
Connect to a 5G network outside your home and distribute powerful Wi-Fi 6 inside your home. With 5G connectivity up to 1.6 Gbps¹ and a built-in Wi-Fi 6 hotspot offering combined speeds up to 1.8 Gbps (574 + 1200 Mbps)², you'll experience vastly increased download speeds, drastically lowered latency, and massively reduced congestion throughout your home network. Wi-Fi 6 is built for device-dense data-intensive environments, which means that the DWR-2101 is powerful enough to support smooth 4K video streaming, low-latency VR gaming, cloud storage, multiple IoT devices, cell phones, tablets, and more – all at the same time.

Take Your Network With You
The DWR-2101 is designed to go where you go, and ready to work where you work. With support for up to 16 devices, a built-in Gigabit port, and the latest 128-bit Wi-Fi security, you can be assured that your network is secure, encrypted and easily scalable. The rechargeable 5260 mAh Lithium-ion battery allows you to stay connected for long periods of time, and it's plug-and-play with no additional set up steps. Whether you're heading away for work, a family adventure or doing some solo traveling, the DWR-2101's all day battery will keep you connected to the Internet.

Easy to Set Up
Getting online with the DWR-2101 is quick, easy, and convenient. Simply insert your 5G or 4G/LTE nano SIM card to set up your very own mobile Wi-Fi network. The DWR-2101 5G Wi-Fi 6 Mobile Hotspot gives you instant connectivity, all in a powerful yet portable device, that fits easily into your bag or pocket.

Frequency Support¹
• 5G NR Sub 6 GHz: n1/3/20/28/78
• LTE FDD: B1/3/5/7/8/20/28
• LTE TDD: B38/40/41/42/46
• WCDMA: B1/B8

• IEEE 802.11n/g/b/ac/ax²

Wireless Frequency Range
• 2.4 - 2.483 GHz
• 5.15 - 5.85 GHz

• 4G LTE/5G 4x4 internal antenna
• 2 x internal Wi-Fi antennas

• Latest 128-bit Wi-Fi security

Advanced Features
• DMZ (Demilitarized Zone)
• Network Traffic Statistics
• SMS messaging
• Power management

Device Management
• Touchscreen
• Web UI

• Nano SIM card slot
• Gigabit Ethernet port
• USB-C port

• LCD Display
 - Network type
 - Signal strength
 - SMS status
• Operator
• Battery status
• Wi-Fi & security status
• Wi-Fi clients

• DC 5 V / 2 A ± 5%
• Rechargeable 5260 mAh Li-ion battery

• 119 x 72 x 23.5 mm (4.7 x 2.8 x 0.9 in)

• 235 g (0.52 lb)

• Operating: 0 to 55 ˚C (32 to 131 ˚F)
• Storage: -30 to 70 ˚C (-22 to 158 ˚F)

• Operating: 10% to 90% (non-condensing)

• CE
• RoHS

Order Information
Part Number
• DWR-2101

• 5G Wi-Fi 6 Mobile Hotspot

¹ Mobile broadband speeds will vary and are dependent on a range of factors including network configuration, network capacity, signal strength, and the conditions of your mobile broadband subscription. A 5G subscription is required in order to achieve maximum speeds.
² Maximum wireless signal rate derived from IEEE Standard 802.11 specifications. Actual data throughput will vary. Network conditions and environmental factors, including volume of network traffic, building materials and construction, and network overhead, lower actual data throughput rate. Environmental factors will adversely affect wireless signal range.

D-Link Corporation datasheet updated 2020/05/11

Scheda tecnica: 1.00 2020/05/11 | 1.01 2020/09/15
Guida installazione: 1.00(EU) 2020/07/17 | 2.00(EU) 2020/12/21
Manuale utente: 1.00 2021/1/5

La guida definitiva per il telelavoro: EN, ES

[In lavorazione!]

Supporto internazionale D-Link
Pagina prodotto: Italia, Globale
Sito FTP: Europa, Polonia, Germania
Supporto tecnico: Taiwan TSD


14 luglio 2020, 15:11:37 #1 Ultima modifica: 13 marzo 2021, 09:25:28 di Pondera

Qualcomm Snapdragon X55

Documentazione multimediale


14 luglio 2020, 15:32:17 #2 Ultima modifica: 19 luglio 2020, 12:02:29 di Pondera
Con l'arrivo del rivoluzionario 5G, i nuovissimi prodotti 5G di D-Link consentono agli utenti di sperimentare velocità incredibili a casa, in ufficio e in viaggio. Il DWR-2101 5G NR MiFi e il DWP-1020 5G NR Outdoor Unit sono stati riconosciuti come vincitori del CES Innovation Award 2020.


14 luglio 2020, 15:35:17 #3 Ultima modifica: 19 luglio 2020, 12:01:56 di Pondera
Recognized as a CES 2020 Innovation Award Honoree, the DWR-2101 is one of the world's first portable hotspots to combine the capacity of Wi-Fi 6 and speed of 5G and can provide high-speed, low latency wireless access at home, at the office, or on-the-go. The DWR-2101 is also ideal for business and leisure travelers as it can support a wide range of international 5G bands.


15 luglio 2020, 15:36:27 #4 Ultima modifica: 19 luglio 2020, 11:58:37 di Pondera

La versione da tavolo DWR-2010, il primo nel suo genere, che ha avuto la stessa onorificenza CES l'anno precedente, si basa sul Qualcomm SDX55. Quindi è probabile che lo monti anche la versione più piccola portatile.

P.S. Come anche il corrispettivo progetto del modello di attrezzatura di rete concorrente (che sembra essere uscito fuori dal produttore fisico reale del fratello minore DWR-932 D1).




21 luglio 2020, 18:33:02 #5 Ultima modifica: 30 agosto 2020, 17:25:19 di Pondera
A quanto pare c'è stato il responsabile senior di sviluppo aziendale della consociata tailandese che lo ha provato... in 4G via WiFi 6 su Intel AX201...


30 settembre 2020, 04:44:49 #7 Ultima modifica: 06 novembre 2020, 09:00:27 di Pondera
Il DWR-2101 inzia a comparire senza immagine sui siti europei di commercio elettronico come Elara in Irlanda, LamdaTek in Francia e notebooksbilliger in Germania.
Disponibilità stimata dal 9 ottobre 2020 20 ottobre 2020 4 novembre 2020 4 gennaio 2021.
Prezzo intorno ai 500€.


La Guida ai prodotti D-Link 2020 (D-Link PRODUCT GUIDE EN/D-Link CATÁLOGO ES) aggiornata a settembre 2020 valida per il mercato EU include adesso anche il modello DWR-2101.


02 novembre 2020, 17:50:37 #9 Ultima modifica: 23 febbraio 2021, 11:00:29 di Pondera
Coincidenze nel numero del nome modello, nella forma, nella schermata dell'interfaccia SO e nella capacità della batteria: Zyxel NR2101 (già disponibile su Amazon IT)!

Fonte: Dustinhome

Ed a quanto pare l'NR2101 è motorizzato con il Qualcomm X55 come già avevamo supposto precedentemente per il DWR-2101.


15 gennaio 2021, 07:46:01 #10 Ultima modifica: 16 gennaio 2021, 09:31:05 di Pondera
Un'altro, con sigla modello DM100 e marchio Onda (già disponibile su Amazon IT)!.

Fonte TIM Onda DM100
